SPOT LED 90 DIAMOND

SPOT LED 90 DIAMOND

Main information:
» Product from category:

Moving Devices / Moving Heads SPOT

» Product series:

DJ

Product codes:
» Product code:

F7100502

DJ
Check series

Product description SPOT LED 90 DIAMOND

SPOT LED 90 DIAMOND is a small moving head with a 90W LED light source. Equipped with 7 color discs + white and two GOBO discs (including one rotating) and a 3-sided prism. Small dimensions and weight, as well as easy operation due to the use of an LED diode, make the device extremely versatile and convenient to use in small rooms or on small stages as well as at larger events.
When buying 4 devices, you receive a dedicated Case, allowing safe storage and transport of devices with accessories.

Specification SPOT LED 90 DIAMOND

Power Source (AC)

Supply voltage 100-240V
Power consumption 90W
Power frequency 50-60Hz

Light source

Type LED
Quantity 1
Power (W) 90
Color Rendering Index (CRI) 65

Color Mixing System

CMY 8 bit

Color Wheel

Color Wheel 7 + White

Dimming

Dimming 8 bit

Beam angle

Beam angle Range

Focus adjustment - Focus

Focus adjustment - Focus Motorized (8 bit)

Prism

Prism 1 3 (Linear)

GOBO Wheel

Static 8
Rotary 6
Rotation 8 bit
Removable slot No

Strobe - frequency

Frequency 1-20Hz
Pulsating Yes
Random Yes

DMX control

Number of modes 1
Number of channels 16

Movement

Range PAN 540 ⁰
Range TILT 270 ⁰
Regulation 16 bit

Modes of operation

DMX512 Yes
Sound control Yes
Auto control Yes
Master-slave Yes

User Interface

Physical buttons Yes
LCD display Yes

Connectors

AC IN PowerCON
AC OUT PowerCON
DMX IN 3-pin XLR
DMX OUT 3-pin XLR

Physical parameters

IP protection level IP20
Housing type ABS
Fixing Mounting hole
Blockade (Pan) No
Blockade (Tilt) No
Housing Color Black
Cooling Active
Length [cm] 28
Width [cm] 18,5
Height [cm] 36
Weight [kg] 6,6

Contents of the package

Manual Yes
Wiring PowerCON
Device SPOT LED 90 DIAMOND

Package dimensions and weight

Package length [cm] 75
Package width [cm] 60
Package height [cm] 56
Weight with packaging [kg] 51
Type of packaging F0901918 CASE FOR 4x SPOT LED 90 DIAMOND

Instructions available SPOT LED 90 DIAMOND

Instrukcja PL for SPOT LED 90 DIAMOND
Instrukcja
Język: PL
Instrukcja EN for SPOT LED 90 DIAMOND
Manual
Language: EN

Dedicated accessories for product SPOT LED 90 DIAMOND
