FLASH DJ BEAM 17R IP65 is an effects moving head designed to produce intense, precisely focused beams of light for concerts, stage productions, club events, and outdoor applications. At its core is a 380 W 17R discharge lamp with a color temperature of 8500 K. The optical system produces a narrow 2° beam, delivering striking aerial effects, particularly when combined with stage fog or haze.
The extensive optical effects system includes a color wheel with 13 colors plus open and a static gobo wheel with 15 patterns and a Shake effect. Two independently controlled prisms — an 8-facet circular prism and a 48-facet circular prism — multiply the beam to create complex lighting compositions. Bidirectional prism rotation with adjustable speed enables both subtle and highly dynamic effects.
Additional creative possibilities are provided by a light Frost filter and a Rainbow effect. The Frost filter diffuses the concentrated beam, giving it a softer appearance, while the Rainbow effect introduces multicolored optical effects. Motorized Focus adjustment allows precise control over gobo projection sharpness, while mechanical dimming from 0–100% and a 1–20 Hz strobe expand the possibilities for programming dynamic lighting sequences.
The moving head offers 540° PAN and 270° TILT movement, with 16-bit control resolution for precise beam positioning. An additional RGB LED ring serves as an independent decorative element, complementing the main light source with colorful illumination on the front of the fixture.
Control is provided via DMX512 (22 channels) with RDM support. Automatic programs, sound control, and Master/Slave operation are also available. A color LCD display and capacitive touch buttons simplify fixture configuration and operation.
The IP65-rated housing provides protection against dust and water jets, allowing operation in demanding outdoor conditions. TrueCON IP65 and 3-pin XLR IP65 connectors provide suitable power and DMX signal connections. Combining a powerful discharge lamp, an extensive effects system, and a weather-resistant construction, the BEAM 17R IP65 is suitable for both stage installations and mobile lighting systems.
When you buy two devices, you receive a dedicated case that allows you to safely store and transport the devices with accessories.
Power Source (AC) |
|
|---|---|
| Supply voltage | 100–240 V AC |
| Power frequency | 50–60 Hz |
| Power consumption | 500 W |
Light Sources |
|
|---|---|
| Main light source type | 17R Discharge Lamp |
| Number of main light sources | 1 |
| Main light source power | 380 W |
| Color temperature | 8500 K |
| Color Rendering Index (CRI) | 65 |
| Additional Light Source Type | RGB LED Ring |
Color Wheel |
|
|---|---|
| Number of Colors | 13 + Open (White) |
| Bidirectional Color Wheel Rotation | Yes |
| Rotation Speed Adjustment | Yes |
GOBO Wheel |
|
|---|---|
| Number of Static Gobos | 15 + Open Position |
| Gobo Shake Effect | Yes |
Prisms |
|
|---|---|
| Number of Prisms | 2 |
| Prism 1 | 8-Facet Circular |
| Prism 2 | 48-Facet Circular |
| Prism Rotation | Bidirectional |
| Rotation Speed Adjustment | Yes |
FROST filter |
|
|---|---|
| Filter Type | Light Frost |
| Control | Motorized |
Rainbow Effect |
|
|---|---|
| Rainbow Filter | Yes |
| Control | Motorized |
Dimming |
|
|---|---|
| Dimming Type | Mechanical |
| Dimming Range | 0–100% |
| Dimming Control Resolution | 8 bit |
Beam angle |
|
|---|---|
| Beam angle | 2° |
Focus adjustment |
|
|---|---|
| Focus adjustment | Motorized |
| Focus Control Resolution | 8 bit |
Strobe |
|
|---|---|
| Frequency | 1–20 Hz |
| Pulse effect | Yes |
| Random effect | Yes |
DMX control |
|
|---|---|
| Number of DMX Modes | 1 |
| Number of DMX Channels | 22 |
Movement (PAN/TILT) |
|
|---|---|
| PAN movement range | 540° |
| TILT movement range | 270° |
| PAN / TILT control resolution | 16 bit |
Modes of operation |
|
|---|---|
| DMX512 | Yes |
| RDM | Yes |
| Automatic Programs (Auto) | Yes |
| Sound Control (Sound) | Yes |
| Master/Slave | Yes |
User Interface |
|
|---|---|
| Buttons | Capacitive (touch) |
| Display | Color LCD |
Connectors |
|
|---|---|
| AC IN | TrueCon IP65 |
| AC OUT | TrueCon IP65 |
| DMX IN | 3-pin XLR IP65 |
| DMX OUT | 3-pin XLR IP65 |
Physical parameters |
|
|---|---|
| IP protection level | IP65 |
| Housing material | ABS |
| Housing Color | Black |
| Mounting System | 2 Mounting Brackets |
| Cooling | Active |
| Operating Temperature | −25°C to +40°C |
| Length [cm] | 36 |
| Width [cm] | 31 |
| Height [cm] | 59 |
| Weight [kg] | 20 |
Included Accessories |
|
|---|---|
| Device | BEAM 17R IP65 |
| Power Cable | TrueCON |
| Mounting Brackets | 2 |
| User Manual | Yes |
Package dimensions and weight |
|
|---|---|
| Package length [cm] | 82 |
| Package width [cm] | 44 |
| Package height [cm] | 81 |
| Weight with packaging [kg] | 68 |
| Type of packaging | F0902003 CASE FOR 2x BEAM 17R IP65 |
