BEAM 12R

BEAM 12R

Main information:
» Product from category:

Moving Lights / Moving Heads BEAM

» Product series:

DJ

Product codes:
» Product code:

F7100581

» EAN: 5905358808993
BEAM 12R /upload/product_series/3/logo-r300x300.webp DJ
Check series
flash
fixtures:
Download now
BEAM 12R 2024-11-15 13:03:39 https://img.youtube.com/vi/At-3-JbsIRQ/hqdefault.jpg https://img.youtube.com/vi/At-3-JbsIRQ/hqdefault.jpg https://www.youtube.com/embed/At-3-JbsIRQ

Product description BEAM 12R

MH-BEAM 12R is a moving beam device, emitting a very narrow, intense beam of light. Equipped with a 12R discharge lamp, color wheels (14 + white), 2x rotating prism 0-400°, motorized focus, ZOOM, filter frost, gobo wheels (13 + open). This reflector is an indispensable element of lighting systems, offering incredible possibilities of creating atmosphere and visual experiences at various events.
When you buy 2 devices, you receive a dedicated Case, allowing safe storage and transport of devices with accessories.

Specification BEAM 12R

Power Source (AC)

Supply voltage 100-240V
Maximum power consumption 1,42A
Power consumption 310W
Power frequency 50-60Hz

Light source

Type DISCHARGE (LAMP 12R)
Quantity 250
Power (W) 250
Color Rendering Index (CRI) 65

Color Mixing System

CMY 8 bit

Color Wheel

Color Wheel 1 14 + white

Dimming

Dimming 8 bit

ZOOM

ZOOM Motorized (16 bit)

Beam angle

Beam angle Range (2-5 ⁰)

Focus adjustment - Focus

Focus adjustment - Focus Motorized (16 bit)

Prism

Prism 1 3 (Linear)
Prism 2 3 (Round)

FROST filter

FROST filter light (smooth)

CTO

CTO smooth

GOBO Wheel

Static 13
Rotary 13
Rotation 8 bit
Removable slot No

Strobe - frequency

Frequency 1-20Hz
Pulsating Yes
Random Yes

DMX control

Number of modes 2
Number of channels 16 / 20

Movement

Range PAN 540 ⁰
Range TILT 270 ⁰
Regulation 16 bit

Modes of operation

DMX512 Yes
Sound control Yes
Auto control Yes
Master/Slave Yes

User Interface

Physical buttons Yes
Color display Yes

Connectors

AC IN PowerCON
AC OUT PowerCON
DMX IN 3-pin XLR
DMX OUT 3-pin XLR

Physical parameters

IP protection level IP20
Housing type ABS
Fixing Mounting hole
Blockade (Pan) No
Blockade (Tilt) No
Housing Color Black
Cooling Active
Length [cm] 30
Width [cm] 24
Height [cm] 50
Weight [kg] 12,6

Contents of the package

Manual Yes
Wiring PowerCON
Device BEAM 12R

Package dimensions and weight

Package length [cm] 65
Package width [cm] 38
Package height [cm] 75
Weight with packaging [kg] 46
Type of packaging F0901993 CASE FOR 2x BEAM 12R
