Archived product

WashFX 1000 IP65

Name: WashFX 1000 IP65
Price: 2306.25 EUR
Availability: InStock

Main information:

» Product from category:

Moving Devices / Moving Heads WASH

» Product series:

ART

Product codes:

» Product code:

F7100754

Check series

See in gallery: Wisłoujście 2023 Concert tours Klub Wytwórnia Concert tours TRANCEFORMATIONS 2024 Concert tours Airbeat One Festival 2023 Concert tours Production of Fokus-Art Kotelnica Summer Festival XXVII Concert tours

MOTORIZED ZOOM
XLR 3-pin
TrueCon IP65
TrueCon
TILT LOCK
TILT
16 BIT DIMMING
PAN LOCK
PAN
MASTER-SLAVE
VARIABLE BEAM ANGLE
IP65
DMX512
BLACK
CTO SMOOTH
ACTIVE COOLING
AUTO CONTROL
ABS

flash

fixtures:

To download fixtures from our database, enter your e-mail address. We will send the files to the e-mail address you provided. By entering the address, you accept statute.

Download now

Product description WashFX 1000 IP65

WashFX 1000 IP65 is equipped with two light sources: 19x40 RGBW and Ring RGB.The device provides smooth brightness control, rotating lenses for both narrow and wide zoom (kaleidoscope effect), built-in shapes and the housing circumference accentuated with an RGB LED strip.Thanks to the IP65 waterproof class and active cooling, it is perfect for outdoor conditions. Additionally, WashFX allows you to change the lighting angle (4⁰-30⁰) and the range of motion (PAN: 540⁰ TILT: 270⁰).

What's new and improved after the software update:1. Improved shapes functionality:Extended and optimized the shapes control functions. This allows for more complex, smooth and dynamic light animations and greater precision in controlling effects
2. New mode with the functionality of popular devices with rings:A dedicated mode of operation has been added, which emulates the functionality of devices with rings. Thanks to this addition, the functionality of the device also increases as a replacement for the Wash 800.
3. Improved shape engine on the outer LED rim zone:The new effects engine on the rings allows each animation to independently control two colors at the same time. This means that each effect on the outer LED rim can be mixed using two different colors, which significantly increases the possibilities of creation.
When purchasing 2 devices, you receive a dedicated Case, enabling safe storage and transport of devices and accessories.

Specification WashFX 1000 IP65

Power Source (AC)
Supply voltage	110-230V
Maximum power consumption	4,35A
Power consumption	1000W
Power frequency	50-60Hz

Light source
Type	LED (RGBW)
Quantity	19
Power (W)	40
Number of control sections	19
Ring	LED (RGB)
Color Rendering Index (CRI)	70,9

Color Mixing System
RGBW	8 bit - 16 bit
RGB	8 bit - 16 bit

Dimming
Dimming	16 bit

ZOOM
ZOOM	Motorized (8 bit)

Beam angle
Beam angle	Zmienny (4⁰-30⁰)

CTO
CTO	2500K - 8000K (Płynny)

Strobe - frequency
Frequency	1Hz-20Hz
Pulsating	Yes
Random	Yes

DMX control
Number of modes	18
Number of channels	21-124

Movement
Range PAN	540°
Range TILT	270°
Regulation	16 bit

Modes of operation
DMX512	Yes
Auto control	Yes
Master-slave	Yes

User Interface
Physical buttons	Yes
LCD display	Yes

Connectors
AC IN	TrueCon IP65
AC OUT	TrueCon IP65
DMX IN	3-pin XLR
DMX OUT	3-pin XLR

Physical parameters
IP protection level	IP65
Housing type	ABS
Fixing	Integrated
Blockade (Pan)	No
Blockade (Tilt)	No
Housing Color	Black
Cooling	Active
Length [cm]	43
Width [cm]	27
Height [cm]	57
Weight [kg]	23,4

Contents of the package
Manual	Yes
Wiring	DMX 3-pin
Wiring	TrueCON
Device	WashFX 1000 IP65
Handle	Integrated

Package dimensions and weight
Package length [cm]	90
Package width [cm]	49
Package height [cm]	77
Weight with packaging [kg]	74
Type of packaging	F0901961 CASE FOR 2x ART WashFX

Instructions available WashFX 1000 IP65

Instrukcja
Język: PL

Manual
Language: EN

Driver fixtures/libraries available

Fixtury GrandMA Dot2 for WashFX 1000 IP65

Fixtury Avolites Titan for WashFX 1000 IP65

Fixtury Avolites Pearl/Azure/Sapphire for WashFX 1000 IP65

Fixtures for visualizers available WashFX 1000 IP65

Documents available WashFX 1000 IP65

DMX Charts EN

_DWG

CAD Symbols & Exterior Dimensions
